30Ft Polyester Endless Round Sling Lift Sling Red 14000LB Vertical USA standards
0 Feet Red Round Sling, Rated Capacity:
VERTICAL: 14,000 LBS (US typical capacity: 13,200 LBS)
CHOKER: 11,200 LBS (US typical capacity: 10,600 LBS)
BASKET: 28,000 LBS (US typical capacity: 26,400 LBS)
Comes with WARNING sheet and safe practice instructions.
It is an endless synthetic sling made from a skein (continuous loop or hank) of polyester yarn covered by a double wall tubular jacket. The roundsling body can also be compared to sling webbing with the tubular jacket face yarns woven without binder yarns; this allows the core yarns to move independently within the jacket.
• Conforms to shape of load to grip securely
• Load bearing yarns protected from UV degradation
• Red striped white core yarns provide added visual warning of sling damage
• Color coding provides positive sling capacity information Saves Money
• Double wall cover for greater sling life
• Soft cover won’t scratch load surface
• Conforms to shape of load for reduced load damage
• Seamless - no sewn edges to rupture prematurely, requiring removal from service
• Color coded capacities for quick identification
• Light weight and pliable for easy rigging and storage
• Independent core yarns choke tightly, but release easily after use
• Easy to carry - high strength to weight ratio for easy transportation All Lift-All slings meet or exceed OSHA and ASME B30.9 standards and regulations. Always protect synthetic slings from being cut by corners and edges. See page 14 Promotes Safety
• Light weight reduces fatigue and strain on riggers
• Synthetic materials won’t cut hands
• Consistent matched lengths for better multiple sling load control
• No loss of strength from abrasion to cover
• Low stretch (about 3% at rated capacity)
 |
|
- How to measure
A polyester roundsling is measured from sling tip to tip when laid in a flat position. It should not be measured by circumference.
It’s also important to note that the round sling diameter refers to the thickness of the core polyester rope, not the fabric jacket cover.
Custom round slings
If you don’t see the size you’re looking for, let us know. Custom lifting slings are always an option at Dahua Sling. sklings in a variety of styles available.
- Sling proof testing certificates
Proof testing certificates are available for a nominal fee and must be requested at the time of ordering. Testing is performed in the factory where the sling is pull tested to 2x the vertical rating and officially recorded as proof for governing bodies. Because only random slings are tested during production, a request must be made prior to manufacturing.
We’re here to help
Have questions? Give our sales team a call today at 0086 25 5705 3551 or drop us email. One of our team members will be happy to help with answers, or to place your order for you.
Important advice for safe lifting
1. Consult DAHUA SLING for configurations not shown on the sling tag or a relevant load chart.
2. Do not use webbing sling if tag is removed.
3. Inspect sling for damage before each use.
4. Do not use sling if there is any sign of a cut cover, snagging, heat or chemical damage, excessive wear, damagedseams, any other defects or presence of grit, abrasive materials or other deleterious material.
5. Do not tie knots in sling.
6. Protect sling from sharp edges of load.
7. Do not expose sling to temperatures above 90°C.
8. Do not allow abrasive or other damaging grit to penetrate the fibers.
9. Consult Yaletech before immersing a sling in a chemical solution.
10. Keep away from strong alkalis and phonetic compounds.
