Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface

Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface

  • Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface
  • Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface
  • Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface
Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface
Product Details:
Place of Origin: China
Brand Name: Dahua Sling
Certification: CE TUV/GS
Model Number: eye eye webbing sling
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: USD 30,000 / 20'GP
Contact Now
Detailed Product Description
Color: As Color Code Eye Protector: White Black Or Same As Webbing
Safety Factor: 5:1 6:1 7:1 8:1 Layer:: Single-layer, Double-layer
Width:: 25mm-300mm Biggest Lifting Sing Factory: Nanjing Dahua Special Belt Knit Co.,Ltd
Chinese Sling Supplier: Nanjing Dahua Special Belt Knit Co.,Ltd HS Code: 5609000000
High Light:

webbing sling belt

,

polyester lifting belts

Duplex eye eye webbing sling, polyester material, produces by DAHUA SLING Since 1993 EN 1492-1



Brief Info



  • Model NO.: FS-01
  • Material: Polyester
  • Fixed Form: Sewing Type
  • Rope Core Type: Polyester
  • Certification: GS, CE, ISO 9001
  • Safety Factor: 5:1, 6:1, 7:1, 8:1
  • Trademark: DAHUA SLING
  • Specification: EN1492-1
  • HS Code: 5609000000

About us



Nanjing Dahua special belt knit Co., Ltd. is a professional manufacturer of lifting and lashing products. We engaged in researching, designing, manufacturing, distributing and providing after-sales services. With more than 20 years of experience, our company is keeping on providing top quality products to the world!





Full company name Nanjing dahua special belt knit
Register date: 1993-01-01
Business License No. 91320100608919015B
Tax No. 320112608919015
Export License Registration No.: 0305519
ISO9001 No. TUV Rheinland [01100038901]
GS No. TUV Rheinland [S502223800001] [S50222380 0002]
Factory Self-owned for 25 years (since 1993)
Workers 187 workers, 60% with 10+ years experience
Export volume yearly 1200 Tons Ratchet Tie Downs
Total Building Size: 24000 Square meters
Office Size: 3800 Square meters
Address: No.2 Changsheng Road, Getang, Nanjing, China 210048
Website: www.dahua-sling.com






1T WEBBING SLING Modelo Color Safety factor Widthmm) M.B.S(kg)
Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface 0

5DEE010

Purple 5:1 25 5T
6DEE010 Purple 6:1 25/38 6T
7DEE010 Purple 7:1 30/50/60 7T
8DEE010 Purple 8:1 50 8T





2T WEBBING SLING Modelo Color Safety factor Widthmm) M.B.S(kg)
Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface 1 5DEE020 Green 5:1 50 10T
6DEE020 Green 6:1 50 12T
7DEE020 Green 7:1 50/60 14T
8DEE020 Green 8:1 65 16T



3T WEBBING SLING Modelo Color Safety factor Widthmm) M.B.S
Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface 2 5DEE030 Yellow 5:1 75 15T
6DEE030 Yellow 6:1 75 18T
7DEE030 Yellow 7:1 75/90 21T
8DEE030 Yellow 8:1 95 24T



4T WEBBING SLING Modelo Color Safety factor Widthmm) M.B.S
Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface 3 5DEE040 Grey 5 100 20T
6DEE040 Grey 6 100 24T
7DEE040 Grey 7 100/120 28T
8DEE040 Grey 8 120 32T



5T WEBBING SLING Modelo Color Safety factor Widthmm) M.B.S(kg)
Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface 4 5DEE050 Red 5:1 125 25T
6DEE050 Red 6:1 125 30T
7DEE050 Red 7:1 125/150 35T
8DEE050 Red 8:1 150 40T



6T WEBBING SLING Modelo Color Safety factor Widthmm)) M.B.S(kg)
Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface 5 5DEE060 Brown 5:1 150 30T
6DEE060 Brown 6:1 150 36T
7DEE060 Brown 7:1 150/180 42T
8DEE060 Brown 8:1 180 48T



8T WEBBING SLING Modelo Color Safety factor Widthmm) M.B.S
Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface 6 5DEE080 Blue 5:1 200 40T
6DEE080 Blue 6:1 200 48T
7DEE080 Blue 7:1 200/240 56T
8DEE080 Blue 8:1 240 64T



10T WEBBING SLING Modelo Color Safety factor Widthmm) M.B.S
Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface 7 5DEE100 Orange 5:1 250 50T
6DEE100 Orange 6:1 250 60T
7DEE100 Orange 7:1 250/300 70T
8DEE100 Orange 8:1 300 80T




CAUTIONS:

- Do not attempt to use sling above rated lifting capacity.
- When selecting a sling,it is very important to consider the angles at which the sling will be used.
- Slings are subject to cutting when ifting items with sharp egeds.In this case,always use protective sleeves
- Do not use a damaged sling,and se only if trained.
- Do not tie knots in sling webbing as strength is greatly reduced.
- Never drag a sling beneth from a load which is resting on it.
- Chemical active environments can affect the strength of slings
- Inspect slings weekly or more frequently depending on the sling use conditions.
- Always strore slings in a cool,dry and dark place to extend the working lift.
- Always read and understand the operating instructions before use.
- Failure to comply with this warning may result in serious load damageand death or injury.





When using flat woven webbing slings always:

• Store and handle belt slings correctly.

• Inspect belt slings and accessories before use and before placing into storage.

• Follow safe slinging practices, as given overleaf.

• Position the bight for choke lift at 120° (natural angle).

• Position the sling so that the load is uniformly spread over its width and protect the sling from sharp edges.

• Apply the correct mode factor for the slinging arrangement.





When using flat woven webbing slings never:

• Attempt to shorten, knot or tie belt slings.

• Expose belt slings to direct heat or flames.

• Use belt slings at temperatures above 80°C or below 0°C without consulting the supplier.

• Expose belt slings to chemicals without consulting the supplier.

• Shock load belt slings.

• Use belt slings which are cut or which have loose or damaged stitching




Duplex Flat Lifting Slings Safety Lifting Belt 5 Ton Wide Bearing Surface 8
