Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings

Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings

    • Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings
    • Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings
    • Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings
  • Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings

    Product Details:

    Place of Origin: China
    Brand Name: Dahua Sling
    Certification: BS EN 1492-1:2000
    Model Number: web sling

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000 pcs
    Price: USD 30,000 / 20'GP
    Contact Now
    Detailed Product Description
    Logo: We Do It Oursleves Eye Protector: White Black Or Same As Webbing
    Material: 100 % Polyester Layer:: 1 Layer
    Packing: Blank Or Printed One Way Sling Sling Type: Endless Flat Webbing Sling
    W.L.L: 250 Kg Endless Sling 750 Kg One Way Sling 1500 Kg Diposable Sling COLOR: Yellow
    Standard: BS EN 1492-1:2000

    Single Use, One Way, Polyester Webbing Seat Belt Round Sling / endless slings. 7:1 Ratio FOS - Range from 250kg to 1000k

    Standard slings are available in 1000mm, 1200mm, 1600mm and 1800mm circumferences which is divided by 2 to calculate the Effective Working Length (EWL), due to them being endless belts, however other lengths are available as special/custom/bespoke units.

    *Safety Factor is calculated as Working Load Limit (WLL) multiplied by a factor of 7 to equal minimum breaking force

    Features

    • Single Use - One Way
    • Low cost, simple design
    • Easy to use
    • Stronger and more compact than rope or wire rope alternative solutions.
    • Can be attached or built in to a structure or load, but must only be used to perform a single complete lift.
    • Saves time and cost on-site slinging and reslinging loads.
    • Fully manufactured, labelled and tested in accordance with BS EN 1492-1:2000 or upon request, manufactured to your commercial specifications with supporting technical file.
    • Available as standard in 25mm, 35mm and 50mm widths in endless format or as bespoke units with loops each end.

    Specimin Test Results

    • Product Type: One Way Sling
    • Webbing type: Polyester Seat Belt
    • Webbing Width: 48mm
    • Test Name: Tensile Test
    • Test Type: Tensile
    • Test Date: 08/03/2007 16:43
    • Test Speed: 100.00mm/min
    • Pretension: 0.050 N
    • Sample Length: 1000.000mm
    • Force at Peak (kN) = 43.910
    • Elongation at Break (mm) = 80.602
    • Time to Failure (Secs) = 48.280



    Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings



    Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings


    Endless sling (Type 5)
    Plies of Web Model Wed Width (in.) Rated Capacity (lbs.) base Length(ft)
    Vertical
    Chocker
    Vertical Basket
    One Ply SEN1-1 1 2400 1920 4800 3
    SEN1-2 2 4800 3840 9600 3
    SEN1-3 3 6600 5280 13200 3
    SEN1-4 4 8800 7040 17600 3
    SEN1-5 5 11000 8800 22000 3
    SEN1-6 6 13200 10560 26400 3
    Two Ply SEN2-1 1 4800 3840 9600 3
    SEN2-2 2 9600 7680 19200 3
    SEN2-3 3 12500 10000 25000 3
    SEN2-4 4 15500 12400 31000 3
    SEN2-5 5 19400 15520 38800 3
    SEN2-6 6 23000 18400 46000 3
