High Tension Heavy Duty Ratchet Strap Webbing 50Mm 5000 Kg Acid Resistance

High Tension Heavy Duty Ratchet Strap Webbing 50Mm 5000 Kg Acid Resistance

  • High Tension Heavy Duty Ratchet Strap Webbing 50Mm 5000 Kg Acid Resistance
High Tension Heavy Duty Ratchet Strap Webbing 50Mm 5000 Kg Acid Resistance
Product Details:
Place of Origin: CHINA
Brand Name: Dahua
Certification: CE GS ISO
Model Number: ratchet webbing material
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: USD 2.8/PC
Packaging Details: PVC bag, carton and pallet
Payment Terms: T/T, L/C
Supply Ability: 5 containers per month
Contact Now
Detailed Product Description
Material: 100% High Strength Polyester Color: Orange, Yellow, Blue Most Popular
Logo: Blank Or Customized Printed Width: 25mm 35mm 50mm 75mm 100mm
Delivery: 20-40 Days For One 20'GP ID Marker: One Grey And One Green As WSTDA Member
B.S: 2000kg 3000kg 4000kg 5000kg 10000kg
High Light:

car tie down straps

,

recovery ratchet straps

High tension strap, 100% polyester fabric roll, webbing for ratchet 50 mm 5000 kg





Specifications

Material: 100% high tenacity Polyester
Specification: 5T
Price: Factory price
Delivery time: in time


All of our Slings are made of A-A Grade polyester yarn.



Product Name

38mm ratchet lashing 4000 kg webbing

Material

Nylon, polyester, pp, etc.

Width

10mm - 200mm

Color/size

Customized

Packing

usually 100 meters/roll, it could be according to client's request

Usages

Widely used for seat belt webbing, lifting, garment, bag-making and Military.

MOQ

5000 meters

Delivery time

3-10 days or based on your quantity

Type of payment

30% deposit in advance, the balance should be paid befor the delivery

Payment

T/T, Western Union, L/C

Shipment methods

By Air - DHL/TNT/UPS/FEDEX/EMS, By Sea


Packaging & Delivery



Packaging Details:

50meter/roll,60meter/roll,4rolls per export carton,16cartons per pallets

Delivery Detail:

Shipped in 35 days after payment



A ratchet tie down is a tool every handyman or cargo control specialist can find multiple uses for. You'll probably want several ratchet tie downs available any time you're securing cargo for transport. A ratchet tie-down can also come in handy for securing items for storage or against high winds. The strap material for our 2" inch ratchet straps is industrial grade webbing. Each strap is securely stitched around the ratchet appliance and end fitting. Straps are available with S hooks ,or you can choose an endless strap for your ratchet tie-downs.

All of our 2" ratchet straps are manufactured with polyester webbing, which offers high strength, and resistance to water absorption and damage from the sun's UV rays, even with repeated outdoor exposure. Because polyester will absorb minimal water, it's also less likely to rot, mildew, or stretch under load. 2" straps are sometimes referred to as large ratchet straps or heavy duty ratchet straps, the polyester webbing offers break strength ranging of 3300lbs.


Why do we choose polyester ratchet webbing?



Fiber Stretch

One of the reasons that tie downs become loose is that the webbing will stretch under a load. Polypropylene is a form of plastic and can stretch over 50% while under load. Nylon tends to stretch between 20 to 30% under a 2500-pound load. Polyester stretches only 5 to 15%, making polyester webbing ideal for heavy loads.



UV Protection

Polyester is highly resistant to UV radiation which means it can stand more prolonged exposure to the sun than Nylon or Polypropylene without the material breaking down.



Water Resistance

Water can affect the strength and durability of tie down webbing materials. Polypropylene and Polyester repel water and are more mildew resistant than Nylon which will absorb water. Nylon webbing becomes much weaker when it is wet and will stretch when it is damp or wet. Polyester webbing can be wet and still be a very strong webbing for tie downs.



Break Strength

The break strength of a webbing material is the maximum stress or load that can be applied to the fabric before failure or it breaks. Polypropylene has a break strength of 700 pounds, Nylon is 2,500 to 7,000 pounds and Polyester is 2,000 to 10,000 pounds.



Abrasion Resistance

Tie down webbing that resists abrasion is extremely important in securing your load. Even seemingly minor webbing damage can significantly reduce the capacity of a tie down to hold objects and increase the chance that the tie down will fail during use. Polyester webbing is more resistant to abrasion than Nylon or Polypropylene.



Overall Safety

Keeping your load safe and secure is extremely important. A tie down must be able to withstand UV radiation, water, and abrasion as well as have a high break strength and a minimal amount of fiber stretch. Using stretchy tie down webbing can cause damage because the stretchy strap lacks the tension needed to keep the load secure. Abraded webbing can increase the chance that the tie down will fail. When comparing overall safety of tie down materials, Polyester webbing is the clear winner.











Tie Down Webbing Comparison

Tie Down Property Polypropylene Nylon Polyester
Overall Safety Poor Fair Excellent
UV Protection Good Good Excellent
Water Resistant Excellent Fair Excellent
Break Strength
(subject to change)
Poor
700 lbs.
Good
2,500 – 7,000 lbs
Excellent
2,000 – 10,000 lbs.
Abrasion Resistance Poor Fair



Excellent
Fiber Stretch Poor
50%
Fair
20%-30%
Excellent
5%-15%

The Clear Choice

Polyester webbing is the best material for your tie down straps. Its resistance against abrasion, UV rays, and water make it a better choice for tie-downs than other webbing materials. It is also mildew resistant which makes it an excellent option for snowmobiles and watercraft. The combination of strength and resistance to stretching and abrasion make it ideal for a strong durable tie-down strap.

Bottom Line

Polyester is more expensive than nylon and this is why most tie-down companies have switched to lower quality nylon for their webbing. ShockStraps use 3,800 pound polyester webbing instead of lower cost nylon so our ShockStrap, and not our webbing, does all the stretching. It’s the reason we don’t have customers calling us to say our hooks are coming off of their load or that their straps are coming loose when traveling down the road.





About us



Slings and webbings are made by NANJING DAHUA SPECIAL BELLT KNIT CO.,LTD , which is specialized in many kinds of flat webbing,includes: luggage webbing, piped tape ,safety belt,military belt,lashing strap, towing strap, full body harness, isolation strap, moving belt, webbing sling, waist belt, pet belt, reflector webbing and so on. The width from 7mm to 300mm , thickness from 0.5mm to 5mm . They are widely used in the fields of car seat belt,bags, military, transportation, protection products, high-altitude working, leisure & gym products, clothing ,shoes and so on.

Just for style reference, we can make samples and mass production to the order.

Our company has the most advanced technology in weaving, colour dyeing, finished products process, quality controlling, priting and fire proof, printing and fire proof.



We have imported warp machines, weaving machines and dyeing machines from Germany, computer control color formula systems from Italy, automatic sewing machines from Japan, testing equipment from Taiwan area.



Dahua Sling has passed ISO9001:2008 quality system.

Most of our products are exported to Japan, America, German and other countries around the world.
