Place of Origin: | Jiangsu, China |
Brand Name: | DAHUA SLING |
Certification: | CE TUV/GS ISO |
Model Number: | Sling webbing |
Minimum Order Quantity: | 3 pallets (about 5000 meters) |
---|---|
Price: | USD 30000 / 20'GP |
Packaging Details: | standard export carton (55*36*24) or big box (110*110*110) |
Delivery Time: | 15- 50 days |
Supply Ability: | 50 containers / month |
SKU: | DAHUA SLING WEBBING | Material: | 100 % Polyester |
---|---|---|---|
Width: | Less Than 300mm | Color: | Any Color |
Stripe: | As Requested | Packing: | 100ft/roll, 100 Meters/roll, 1680 Meters/box |
Logo: | Available | Capacity: | As Requested |
High Light: | heavy duty polyester webbing,polyester webbing tape |
Full company name | Nanjing dahua special belt knit Co.,Ltd |
Register date: | 1993-01-01 |
Business License No. | 91320100608919015B |
Tax No. | 320112608919015 |
Customs Registration No.: | 3201930613 |
| Mr. Pan wang |
Mr. Gao Changchun | |
Tel: | 0086 25 5705 3551 |
ISO9001 No. | TUV Rheinland [01100038901] |
GS No. | TUV Rheinland [S502223800001] [S50222380 0002] |
Factory | Self-owned for 25 years (since 1993) |
Workers | 187 workers, 60% with 10+ years experience |
Export volume | yearly 1200 Tons Ratchet Tie Downs |
Total Building Size: | 24000 Square meters |
Office Size: | 3800 Square meters |
100% Polyester Webbing Sling Material - Qingdao Yanfei Rigging Supplier
Material: 100% Polyester
Standard: ISO4878 EN1492-1 ASME B30.9
Safety Factor: 6:1 7:1 8:1
Package: 100m/roll or others, carton, pallet
STRIPES INFO
Width, mm | Color | Webbing (MBL, kg) | Number of stripes |
30 | Violet | 4500 | 1 |
60 | Green | 9000 | 2 |
90 | Yellow | 13500 | 3 |
120 | Grey | 18000 | 4 |
150 | Red | 22500 | 5 |
180 | Brown | 27000 | 6 |
240 | Blue | 36000 | 8 |
300 | Orange | 45000 | 10 |
WEBBING INFO
Safety Factor 6:1
SKU | Width(mm) | Color | M.B.S(kg) |
E6W010 | 25/38 | Purple | 3750 |
E6W020 | 50 | Green | 7500 |
E6W030 | 75 | Yellow | 11250 |
E6W040 | 100 | Grey | 15000 |
E6W050 | 125 | Red | 18750 |
E6W060 | 150 | Brown | 22500 |
E6W080 | 200 | Blue | 30000 |
E6W100 | 250 | Orange | 37500 |
E6W120 | 300 | Orange | 45000 |
Care and Use
1. Check European Standard for use and inspection guidelines.
2. Never attempt to lift load over load capacity
3. Do not use if ID tag is removed.
4. Inspect sling for damage prior to use.
5. Do not use sling if there is any sign of cut webbing, snagging, heat or chemical damage, excessive wear, damaged seams, any other defect or presence of grit, abrasive materials or other deleterious matter.
6. Do not tie knots in sling webbing.
7. Protect sling webbing from sharp edges of load. Use protective sleeves.
8. Do not expose slings to temperatures above 90°C.
9. Do not allow abrasive or other damaging grit to penetrate the fibres.
10. Consult with RELIABLE SLING recommendations before immersing a sling in a chemical solution.
11. Keep away from strong alkalis and phenolic compounds.
